For Ford Explorer Escape Lincoln TPMS Reset Tool Tire Pressure Sensor Training

For Ford Explorer Escape Lincoln TPMS Reset Tool Tire Pressure Sensor Training

Main Features: 1. TPMS Relearn TPMS light lights up, change tire or tire sensor,enter car TPMS relearn mode, use this tool and relearn, this TPMS light will turns off. 2. TPMS tire sensor condition diagnostic Press the button of this device,LED flash, however,replace tire or tire sensor does not do any response, this tool could help car owner judge this tire sensor condition, usually, it requires brand new tire sensor. Most of situation, the tire sensor are bad, TPMS information missing,or battery ran out.

When do you need this tire pressure sensor reset tool?

Please check the exact car model list to confirm if your car is compatible with the EL-50449 tpms tool.

Tips for using:

[1] When using the EL-50449 TPMS relearn tool, make sure the antenna is in the correct position. If it is not in the correct position, it will not receive the sensor signal, meaning the product will not work properly. (The position of the tires is also important, Front tires have to be straight)

[2] Heavy trucks are not supported.;

[3] Please use NEW 9V battery (not include in package), the magnitude of the battery voltage affects the signal strength of the product

[4] Sensors should be original OEM sensors which well programmed;

[5] Only support 315MHz and 433MHz frequency, not support other frequency;

[6] The TPMS tool is unable to reprogram sensors, it's a TPMS reset tool;

[7] For different vehicles JDIAG EL50449 may need different times to reset all of your tire sensors after rotation;

EL-50449 TPMS relearn tool supports the vehicle specified in the picture, if your model is not mentioned in the picture or your model is mentioned but the year does not match, it means our tool is not compatible with your vehicle.

EL-50449 TPMS relearn tool supports the vehicle specified in the picture, if your model is not mentioned in the picture or your model is mentioned but the year does not match, it means our tool is not compatible with your vehicle.

9V Battery Required

• Please make sure to use a Brand NEW 9V battery, the battery is not included in the package, and the magnitude of the battery voltage affects the signal strength of the product.

Correct Position

• When using the EL-50449 TPMS relearn tool, make sure the antenna is in the correct position. If it is not in the correct position, it will not receive the sensor signal, meaning the product will not work properly.

• The position of the tires is also important, Front tires have to be straight.

How to use the resetting button?

1. Press and hold the button over 3 seconds for power on or off.

2. Press and release the button for activating tire sensors;

NOTE:

1. If TX indicator doesn't light up when press the button, it means the tool is power off, you should turn it on by pressing and holding the resetting over 3 seconds before use!

2. If you turn off the tool, even you load new battery, it doesn't work!

Top

About this item

Reviews

Trouble shooting

Q: Press button of this device, the indicator light of this device flick.However, I does not heard any response. TPMS relearn not successful.

A: Following our correct step operation. (See our product photo showing.) Enter car TPMS relearn mode first, and operation this device. It could not directly operation.

Install a set of tire sensors (marked 'Programmed' on shell) replace old ones. 90% of situation of our clients encounter this situation by this reason. Some new tire sensors,

lack of TPMS information.

Q: When I install brand new 9V battery,the power light of this device does not works,is it fault?

A: Make sure two poles of battery at correct location. Press button and check indicator light of this device, it needs press button at long time. Release button,the light will does not works.

Q: The indicator light does not turn on. How to deal with this?

A: It depends on the specific operation. If no TPMS reset operation has been performed yet, replace the battery. If the issue persists after replacing 2 to 3 batteries, take a photo and send

a message to the seller to request a replacement.

If the indicator light is flashing but the car does not respond, it is caused by improper operation. Refer to the correct operation method for this item.

Q: After pressing the button on this item, the indicator light flashes, but one or more, or all of the car tires do not respond.

A: First, it is important to understand that if the indicator light flashes, it means the item is sending signals normally to the TPMS sensors in the car tires, and it is not a defect in the item.

Do not rush to open an after-sales dispute for the order at this point. Read the following content. If the issue is still not resolved, send a message to the seller for assistance.

Q: The indicator light of this device does not lights up, I installed brand new 9V battery.

A: It needs press button at lasts time( lasts 2 to 4 seconds), otherwise, it will flash at short time, it maybe cause you misunderstanding this device does not lights up.

General Process for TPMS Light Reset

1. The car’s TPMS light flashes.

2. Replace the TPMS sensor. Note: The original TPMS sensor must be replaced with a set of TPMS sensors marked with "Pre-coded". Other third-party brand sensors, unless claimed to

be pre-programmed, will have no TPMS information at this stage.

3. After installing the TPMS sensors, put the car into TPMS reset mode.

4. Follow the correct operation method for this item. Proceed clockwise, starting with the left front tire as the first tire, until all four tires are completed. If you hear a beep sound from

the car, it indicates TPMS success. Otherwise, it indicates failure.

If during the operation, the item is sending information (the indicator light is flashing), but one or more car tires do not respond, check whether the operation method differs from what

we have provided (refer to the videos and images of our item). Alternatively, it may be caused by the car’s TPMS sensor. If it is due to the tire sensor, replace it with TPMS sensors marked

with "Pre-coded" and repeat the operation to resolve the issue.
