368417 RV Slide Out Motor (Power Gear Replacement)
Updated June 19, 2026
The 368417 RV slide out motor is a permanent magnet, parallel shaft gear motor designed to extend and retract slide-out rooms on recreational vehicles. It serves as a direct replacement for Power Gear slide out motors with part numbers 1010000010 and 1510000006. This motor operates at 14 RPM under no load, providing the torque needed to move heavy slide-out assemblies smoothly.
AI-generated content
How It Works & Design
This motor uses a permanent magnet DC design with a parallel shaft gear reduction. When 12V power is applied, the armature rotates, and the gear train reduces speed while increasing torque to move the slide-out mechanism. The 14 RPM no-load speed is typical for RV slide-out applications, balancing speed with the high torque required to overcome friction and weight. The motor is sealed to protect against dust and moisture common in under-vehicle or chassis-mounted locations.
Vehicle Fitment & Compatibility
The 368417 motor is specifically engineered for Power Gear slide-out systems found in many motorhomes, fifth wheels, and travel trailers. It directly replaces OEM part numbers 1010000010 and 1510000006. It is not compatible with Lippert, Schwintek, or other slide-out mechanisms without adapter brackets or wiring changes. Always verify your existing motor's part number and mounting pattern before purchase.
Common Failure Symptoms & Diagnosis
Symptoms of a failing slide-out motor include the slide room moving slowly or stopping mid-travel, unusual grinding or clicking noises, or the motor running but the slide not moving. Electrical issues such as a blown fuse or corroded connections can mimic motor failure. To diagnose, check for 12V at the motor terminals while the switch is activated; if voltage is present but the motor does not run, the motor is likely defective. A seized gearbox may also prevent rotation.
Replacement & Installation Notes
Begin by disconnecting the RV battery and removing any interior trim or access panels covering the slide-out mechanism. Unbolt the old motor from its mounting bracket, disconnect the wiring harness, and remove it. Install the new motor in the same orientation, ensuring the output shaft aligns with the drive gear or chain. Reconnect wiring, secure the motor, and test the slide-out through a full cycle before reinstalling trim. Proper alignment is critical to prevent binding or premature wear.
